RICOH IM C6500

General

Model

RICOH IM C6500

Printing process

4-drum dry electrostatic transfer system with internal transfer belt

Warm-up time

45 seconds

First output speed: B/W

5.5 seconds

First output speed: full

colour

7.5 seconds

Continuous output speed

65 ppm

Power source

120V – 127V / 16A, 60Hz

Memory

4 GB

HDD: standard

640 GB (320 GB x 2)

Dimensions: W x D x H

29.5” x 34.7” x 48.3” (750 x 880 x 1,225 mm)

Multiple copying

Up to 999 copies

Copy resolution

600 x 600 dpi

Zoom

From 25% to 400% in 1% steps

CPU

Intel® Apollo Lake Processor 1.6 GHz

Printer language

PCL5c, PCL6, Adobe® PostScript® 3™ (emulation), PDF direct (emulation)

Print resolution

2,400 x 4,800 dpi

Network interface

Wireless LAN (IEEE 802.11a/b/g/n), RJ45 I/F (Only Copy connect), Ethernet Print only RJ-45 network port

Scanning: B/W; Colour

120 ipm (simplex) / 240 ipm (duplex)

Scanning Resolution

600 dpi (1,200 dpi via TWAIN)

Bundled drivers

Network TWAIN

File formats

Single page: TIFF, JPEG, PDF, High compression PDF, PDF/A Multi page: TIFF, PDF, High compression PDF, PDF/A

Scan modes

E-mail, Folder, USB,SD Card, URL, FTP,SMB

Power consumption:

maximum

Less than 1,920 W

Transmission speed

G3: approximately 3 seconds (200 x 100 dpi, MMR, ITUT #1 chart TTI off, memory transmission)

Modem speed

33.6 Kbps

Resolution

Standard mode: 8 x 3.85 line/mm, 200 x 100 dpi Detail mode: 8 x 7.7 line/mm, 200 x 200 dpi Super fine mode: 8 x 15.4 line/mm, 16 x 15.4 line/mm, 400 x 400 dpi (with optional SAF memory)

Paper input: standard /

maximum

standard:  3,700 sheets                                          maximum: 8,100 sheets

Paper output standard/

maximum

standard:  500 sheets                                        maximum: 3,500 sheets
